Site Investigation Case Studies

At In Situ Site Investigation, we have completed hundreds of CPT, seismic and pressuremeter jobs all over the world and the UK. Please see below for a selection of case studies demonstrating our cones and equipment for a sample of the work we do.

Please get in touch if you would like a quote for your upcoming project.

Seismic Research Project in Folkestone with Imperial College

We have just completed a research project in Folkestone with a student from Imperial College London. The tracked rig and seismic equipment was used. The aim was to verify a projected geological model of the ground underneath the seismic station as well as investigating the likely shear wave (seismic) speeds in the top few metres of ground. The testing went very well and the resulting data will be used to improve modelling of such station sites, hopefully increasing the safety of sensitive infrastructure in the future.

Read More

Isle of Wight

When you think the holiday season has gone for another summer there was just enough time to for a quick break to the Isle of Wight with In Situ’s White Crawler aka Erik.

Read More

Madagascar, Fort Dauphin

In the South Eastern area of Madagascar, In Situ also carried out a project for Rio Tinto close to the town of Fort Dauphin.  The investigation was similar to another project we carried out in Mozambique where we were investigating the density of the high mineral content sands.

Read More

Birmingham City University

In Situ has been involved in an exciting project for a new building for Birmingham City University.  Our part of the project was to clear areas of the site for Unexploded Ordnance.

Read More

Swansea Bay

In Situ have been involved in an exciting renewable energy project at Swansea Bay. The Swansea Bay Tidal Lagoon project is aiming to be the world’s first man-made, energy-generating lagoon, with 250MW of installed tidal power capacity.

The project involved carrying out combined CPT and Magnetometer tests at locations in the intertidal zone where the proposed lagoon is to be built.

Read More

Seismic Research Project

In Situ have recently finished working with a University of Birmingham 4th year Civil Engineering student, developing geophysical research relating to the maximum shear modulus values of a soil, for a final year MEng geotechnical project.

Seismic cone penetration tests were undertaken before and after the installation of vibro-stone columns to establish the effectiveness of the ground improvement technique, and the feasibility of using geophysics.

Read More

Agricultural University of Kamza, Faculty of Economics, Albania

The site is located in the grounds of the Agricultural University of Kamza, about 10 km north of Tirana, capital city of Albania.

In Situ Balkans carried out a ground investigation for T.T. – Soil & Earthquake Consulting to determine the ground conditions close to the Faculty of Economics, whose building has severe damage in the foundations and cracks in the walls.

Read More


In Situ was involved in a large geotechnical investigation for one of Rio Tinto’s exploration projects in Mozambique. The job entailed carrying out over 200 CPTs in the densely vegetated jungle of Jangamo close to the town of Inhambane.

Read More

River Crossing

In Situ carried out an over-water based ground investigation for the client. The aim of this investigation was to determine the ground conditions on the river bed, and the locations for the proposed bridge foundations.

Read More


In Situ Carried out a project investigating an old clay pit on the putskirts of Telford. The project involved carrying put 136 CPTs to depths between 1 and 10m across the site.

The site had been backfilled up to its present level, leaving a relitively flat area for the construction of a housing estate. Before the building work commenced information was required regarding the thickness and geotechnical parameters of the variable fill on the site.

Read More

Durres, Albania

In December 2013, In Situ Balkans, carried out 7 CPTs and 1 DMT in the area of Golemi beach, in Durresi city, Albania. This was a research project and the client will use the results of the In Situ investigation to study the liquefaction potential of the 7 km long area.

Read More

Albania, Trans Adriatic Pipeline

In Situ SI carried out a site investigation at Compressor Station CS-03 and Landfall area, as part of the Trans Adriatic Pipeline project (TAP). The sites were both located in the western part of Albania, near the Semani beach. The Trans Adriatic Pipeline (TAP) supports the European Union’s strategic goal of securing future energy supply. TAP will transport natural gas from the giant Shah Deniz II field in Azerbaijan, via Greece and Albania, and across the Adriatic Sea to Southern Italy, and further to Western Europe.

Research Project with University of Ireland, Galway at Keller’s Yard

As part of In Situ’s continued research into Cone Penetration Testing we have teamed up with the Civil Engineering department at the University of Ireland, Galway and Keller.

Read More


This site had been identified for the installation for a windfarm, the site was agricultural land and was unsuitable for the wheeled CPT truck, however the blue tracked crawler was perfect for the terrain.

Read More

The Wash, Lincolnshire

In Situ Site Investigation carried out a survey for a cable route at The Wash in Lincolnshire; the survey was to investigate a cable route from an offshore windfarm.

Read More
